Technikai paraméterek
Standard interior configuration
ENTERANCE
Cockpit closeout privacy curtain
Spacious galley with generous work surface, drainable ice drawer and available microwave
Sound-insulating sliding-door separating entrance from main cabin available
Wardrobe for passengers’ and crew members’ personal items
FURNISHINGS
Flexible seating arrangements for up to 9 passengers
Executive seating in club configuration
Seats feature ergonomic swivel and recline
Quick-access seat storage compartments
Stowable table at each executive seating arrangement
CONNECTIVITY AND ENTERTAINMENT
High definition forward bulkhead monitor
High-speed internet connectivity available
Audio/Video on Demand available
Plug-and-play entertainment
experience with universal HDMI and USB ports
Full control of cabin environment and entertainment through 7 in (17.8 cm) touch screens at every seat
LAVATORY AND STORAGE
Lavatory benefiting from natural lighting featuring a large mirror, vanity, sink and faucet
External 50 ft³ (1.4 m³) heated baggage compartment with an additional 15 ft³ (0.4 m³) of internal storage
TECHNICAL SPECIFICATIONS
GENERAL
| CAPATCITY | |
|---|---|
| Passengers: Up to 9 |
| ENGINES | |
|---|---|
| Honeywell TFE731-40BR | |
| Thrust: 3,850 lbf (17 kN) | |
| Flat rated to ISA +23°C, SL |
| AVIONICS | |
|---|---|
| Touch screen controllers | |
| Garmin G5000 with three high resolution 14 in (35.6 cm) displays | |
| Dual Flight Management System | |
| Graphical flight planning | |
| Advanced weather radar | |
| Datalink capabilities |
PERFORMANCE
| RANGE | ||
|---|---|---|
| Maximum Range(1) | 2,040 nm | 3,778 km |
| SPEED | MACH |
|---|---|
| Top speed | 0.81 |
| High speed cruise | 0.79 |
| Typical cruise speed | 0.76 |
| AIRFIELD PERFORMANCE | ||
|---|---|---|
| Takeoff distance (SL, ISA, MTOW) | 4,440 ft | 1,353m |
| Takeoff distance (SL, ISA, MTOW) | 2,325 ft | 709m |
| OPERATING ALTITUDE | ||
|---|---|---|
| Maximum operating altitude | 51,000 ft | 15,545 m |
| Initial cruise altitude (MTOW) | 45,000 ft | 13,716 m |
DIMENSIONS
| INTERIOR | ||
|---|---|---|
| Cabin height | 4 ft 11 in | 1.50 m |
| Cabin width | 5 ft 1 in | 1.56 m |
| Cabin length (2) | 19 ft 10 in | 6.04 m |
| EXTERIOR | ||
|---|---|---|
| Length | 58 ft 0 in | 17.7 m |
| Wingspan | 50 ft 11 in | 15.5m |
| Wing area | 309 ft2 | 28.7 m2 |
| Height | 14 ft 0 in | 4.3 m |
| WEIGHTS | ||
|---|---|---|
| Maximum ramp weight | 21,750 lb | 9,866 kg |
| Maximum takeoff weight | 21,500 lb | 9,752 kg |
| Maximum landing weight | 19,200 lb | 8,709 kg |
| Maximum zero-fuel weight | 16,500 lb | 7,484 kg |
| Basic operating weight | 13,890 lb | 6,300 kg |
| Maximum fuel weight | 6,062 lb | 2,750 kg |
| Maximum payload | 2,610 lb | 1,184 kg |
(1) Theoretical range with NBAA, IFR Reserves, ISA, LRC, 4pax/2 crew. Actual range will be affected by speed, weather, selected options, and other factors.
(2) From cockpit divider to aft most cabin without baggage compartment.
